| MODEL | MU5702 | ||
|---|---|---|---|
| Drive System | 4WD | ||
| ENGINE | Type | Direct injection, with turbocharger water-cooled 4 cycle diesel | |
| Model | V2403-M-DI-T | ||
| Net power | HP(kW) | 54.5 | |
| Max. power | HP(kW) | 57.1 | |
| PTO power | HP(kW) | 36.4 (48.9) | |
| Bore and stroke | mm | 87 x 102.4 | |
| Total displacement | cc | 2434 | |
| Rated revolution | rpm | 2400 | |
| Max. torque | N-m | 213.8 | |
| Battery | 12 V / 55 Ah | ||
| Fuel tank capacity | ℓ | 65 | |
| Traveling System | Front | inch | 9.5 - 24 |
| Rear | inch | 16.9 - 28 | |
| Main transmission | Synchromesh | ||
| Directional transmission | Synchro Shuttle | ||
| Transmission | Gear shift, 8 forward and 8 reverse | ||
| Steering | Hydrostatic power steering | ||
| Braking system | Mechanical, wet disc type | ||
| Clutch | Single dry-type | ||
| Front wheel drive system | Complete helical gear (Bevel gear) | ||
| Turning radius (with brake assistance) | m | 3 | |
| Speed | Forward (km/h) | 3.1 - 31.7 (max 35.1) | |
| Backward (km/h) | 3.1 - 32.2 | ||
| Power take off system (PTO shaft) | Standard size | SAE 1-3/8 inches 6 splines | |
| PTO speed (engine speed) | rpm | 540 at 2,258 engine speed 750 at 2,196 engine speed | |
| Hydraulic system | Pump flow rate | ℓ /min. | 30.5 |
| Hydraulic control system | Position, draft (top link sensing) and mix control | ||
| 3-point hitch | Category 2 | ||
| Max. lift force | At lift point (kg) | 1800 | |
| 24 inch behind lift point (kg) | 1550 | ||
| Dimension/ weight | Weight (without ballast) | kg | 2,350 |
| Overall length (without 3P and front ballast) | mm | 3,250 | |
| Overall width (min. tread) | mm | 1950 | |
| Overall height (to top of ROPS) | mm | 2450 | |
| Wheelbase | mm | 2050 | |
| Min. ground clearance | mm | 415 | |
| Tread | Front Wheel (mm) | 1445, 1475, 1560, 1590, 1645, 1675, 1755, 17485 | |
| Rear Wheel (mm) | 1520, 1630, 1710, 1820 | ||
